What is a 4-point wheelchair tie-down system?

A 4-point tie-down uses four retractors or straps — two at the front and two at the rear of the wheelchair — to secure the chair to the vehicle floor. When combined with a lap and shoulder belt for the occupant, it meets federal ADA and WC18 securement standards for paratransit, NEMT, and school bus transport.

Is wheelchair securement required by law?

Yes. The Americans with Disabilities Act (ADA) requires that all public transit vehicles equipped to transport wheelchair users must have an approved securement system. NEMT providers, paratransit operators, and school bus fleets are all subject to federal and state securement regulations. Failure to comply can result in fines and significant liability in the event of an accident.

What does WC18 compliant mean?

WC18 is the RESNA/ANSI standard that defines performance requirements for wheelchair tie-down and occupant restraint systems (WTORS). WC18-compliant products have been crash-tested to withstand higher load forces than previous standards, providing greater protection for wheelchair users in the event of a collision or sudden stop.

Which wheelchair securement brands do you carry?

We are an authorized dealer for Q'Straint, AMF Bruns, and Sure-Lok — the three leading manufacturers of wheelchair tie-down and occupant restraint systems worldwide. All products meet or exceed WC18 compliance standards where applicable.

What is the difference between an L-track and a Slide N' Click system?

L-track is a recessed floor channel that accepts fittings at any point along its length, giving installers maximum flexibility in retractor placement. Slide N' Click is Q'Straint's proprietary system using pre-set anchor points that allow faster, tool-free securement — popular in high-volume paratransit operations where speed of securement matters.

What is the difference between a manual and retractable wheelchair strap?

Manual straps are fixed-length webbing straps with a hook or loop connection — simple, affordable, and reliable. Retractable systems use a spring-loaded mechanism to automatically take up slack, making securement faster and reducing trip hazards from loose webbing. Electric retractors add powered retraction, ideal for operators or drivers with limited hand strength or mobility.

Do you offer fleet pricing for multiple vehicles?

Yes. We offer fleet pricing for operators outfitting five or more vehicles. Submit your vehicle count, vehicle type, and preferred brand through our Fleet Quote form and a specialist will respond within one business day.

Do your products come with installation instructions?

Yes. All products ship with manufacturer installation guides. We also maintain a full library of installation and user guides on our website for Q'Straint, AMF Bruns, and Sure-Lok products. Our specialists are also available by phone at 800.884.6456 if you need installation support at no charge.

FREE STANDARD SHIPPING ON ORDERS OVER $100 - 800.884.6456

Q04BR133 | Rigid Sport-Frame Wheelchair/Lightweight QLK-150 Bracket

Vendor: Q'Straint
Regular price: $1,110.95
Sale price: $1,110.95
Unit price: per

Shipping calculated at checkout.

Q'Straint QLK docking system provides automatic front wheelchair securement as the wheelchair rolls forward into the vehicle. Meets the highest safety standards (ANSI/RESNA WC18, SAE J2249, ISO 10542). Low-profile design reduces interference and offers a sleek, finished look. The largest wheelchair bracket compatibility list of any docking system on the market.

SKU: Q04BR133 | VENDOR: Q'STRAINT

Q04BR133 | Rigid Sport-Frame Wheelchair/Lightweight QLK-150 Bracket

✔ Free Shipping 🔒 Front Docking System 🏷 Q'Straint

Key Features

🏆

Only Docking System to Pass WC19 Loads

The QLK-150 is currently the only docking system tested and certified to WC19 wheelchair load requirements — tested forward, rearward, and sideways.

⚡

Ultra-Low Power Draw

In sleep mode the system draws just 76.5 micro amps — approximately 5x less than other docking systems, minimizing vehicle battery drain between uses.

📋

Largest Bracket Compatibility List

Hundreds of exclusive wheelchair brackets covering thousands of models — more wheelchair-specific brackets than any other docking system on the market.

🔒

Advanced Stabilizer Option

Optional Advanced Stabilizer allows QLK-150 installation in the driver position without sacrificing wheelchair drivability.

What's Included

Qty	Component	SKU
1	Q04BR133	Q04BR133

Full Feature Details

Key Feature Summary

Feature	Description
Only Docking System to Pass WC19 Loads	The QLK-150 is currently the only docking system tested and certified to WC19 wheelchair load requirements — tested forward, rearward, and sideways.
Ultra-Low Power Draw	In sleep mode the system draws just 76.5 micro amps — approximately 5x less than other docking systems, minimizing vehicle battery drain between uses.
Largest Bracket Compatibility List	Hundreds of exclusive wheelchair brackets covering thousands of models — more wheelchair-specific brackets than any other docking system on the market.
Advanced Stabilizer Option	Optional Advanced Stabilizer allows QLK-150 installation in the driver position without sacrificing wheelchair drivability.

Vehicle Applications

🚐 Wheelchair-Accessible Van (WAV)🚗 Personal Vehicle / Minivan🚑 Non-Emergency Medical Transport (NEMT)🚐 Sprinter / Transit Van

Standards & Compliance

ISO 10542Wheelchairs — Tie-Down & Occupant Restraint Systems

RESNA WC18Wheelchair Tie-Down & Restraint Systems — Heavy Duty (ANSI/RESNA)

FMVSS 209Seat Belt Assemblies

FMVSS 210Seat Belt Assembly Anchorages

FMVSS 302Flammability of Interior Materials

CSA Z605Wheelchair Securement in Motor Vehicles (Canada)

ℹ️ ADA Compliance Note: This product is designed for use in ADA-accessible transportation applications. Verify that installation meets applicable ADA requirements for your specific vehicle type and use.

🔒 WC18 Certified: This product meets ANSI/RESNA WC18 — the crash-tested standard for heavy-duty WTORS hardware. For procurement language and certification documentation, see our RESNA WC18 Standard Guide.

🛡 Warranty: 3-year limited. * Registration required at qstraint.com for full coverage. Without registration, 1-year limited applies.

⚠ Warranty terms should be verified directly with the manufacturer.

⚠ California Prop 65 Warning: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. See qstraint.com/prop-65

📄 QLK Bracket Guide: View QLK Bracket Instruction List | All User Guides

📄 Product Documents: INSTALLATION INSTRUCTIONS | here

Specifications

Specification	Detail
Brand	Q'Straint
SKU	Q04BR133
Price	1110.25 — price shown is per unit
Shipping	Free Shipping
Warranty	3-year limited
Use / Installation	Professional installation required by a certified WAV modifier.

Frequently Asked Questions

What is a wheelchair docking system? +

A docking system secures the front of a WC19-compliant wheelchair to the vehicle floor as it rolls into position. Rear 2-point tie-downs and an occupant belt are still required to complete the full securement system.

Does my wheelchair need to be WC19 compliant? +

Yes. Docking systems require a WC19-compliant (transit) wheelchair with four standard anchor points and an integrated lap belt attachment. Check with your wheelchair manufacturer.

Is professional installation required? +

Yes. Docking base mounts must be professionally installed by a certified WAV modifier.

What is the warranty? +

See the Warranty section above. Registration at qstraint.com is required for full warranty coverage.
